ISL97671A
Revision History
The revision history provided is for informational purposes only and is believed to be accurate, but not warranted. Please go to web to make sure you
have the latest Rev.
DATE
October 3, 2012
July 11, 2012
March 24, 2011
REVISION
FN7709.3
FN7709.2
FN7709.1
CHANGE
Minor changes to improve the wording of various sections.
page 5 - Thermal Information, removed Pb-Free Reflow Profile link.
page 6 - V OVPlo in the spec table, changed to Min 1.199 and Max 1.24 from Min 1.19 and Max 1.24
page 8 - Figure 3 “EFFICIENCY vs up to 20mA LED CURRENT (100% LED DUTY CYCLE) vs VIN” removed.
page 9 - Figures 11, 12 replaced to clear waveforms
page 12 & page 16 respectively, Tables 1, 2 improved.
page 18 - I 2 C section, specified that the backlight can turns on when SDA/SCL are connected to ground.
page 20 - Improved description of PWM_MD and PWM_SEL I 2 C register bits. Corrected Figure 30.
Removed Direct PWM and PWM-to-DC register bits from the description
PWM-to-DC bit and BstSlewRate bit in the register 0x08 updated on page 19, page 22 and page 23.
In “Current Matching and Current Accuracy” on page 11, changed 401.8 to 410.5.
On page 11 Equation 1, changed 401.8 to 410.5.
Initial Release to web.
About Intersil
Intersil Corporation is a leader in the design and manufacture of high-performance analog, mixed-signal and power management
semiconductors. The company's products address some of the fastest growing markets within the industrial and infrastructure,
personal computing and high-end consumer markets. For more information about Intersil or to find out how to become a member of
our winning team, visit our website and career page at www.intersil.com .
For a complete listing of Applications, Related Documentation and Related Parts, please see the respective product information page.
Also, please check the product information page to ensure that you have the most updated datasheet: ISL97671A
To report errors or suggestions for this datasheet, please go to: www.intersil.com/askourstaff
Reliability reports are available from our website at: http://rel.intersil.com/reports/search.php
For additional products, see www.intersil.com/en/products.html
Intersil products are manufactured, assembled and tested utilizing ISO9000 quality systems as noted
in the quality certifications found at www.intersil.com/en/support/qualandreliability.html
Intersil products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design, software and/or specifications at any time
without notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be
accurate and reliable. However, no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third
parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Intersil or its subsidiaries.
For information regarding Intersil Corporation and its products, see www.intersil.com
